Clocks and Timers

Sophisticated signal distribution and synthesis components
| Serial & Parallel BERTs | Probe Products | Video Demo |

견적 요청 자료실

| 제품 설명

Modern data center, telecommunications, and signal processing systems rely on highly sophisticated clock and timer solutions. These solutions include programmable clock generators, clock fanout buffers, and delay elements. Since all of these elements ultimately define the jitter performance of high-speed signal chains, they require careful design and validation.

Introspect Technology’s C Series line of products are ideal for the characterization of PLLs within clock and timer circuits. They are also ideal for skew measurement and analysis, offering a cost-effective alternative to high-end tools such as oscilloscopes.

Industry Challenges	Introspect Capability
- Large channel counts - Complex frequency combinations - Low-voltage differential signaling - Very low jitter levels	- Up to 32 channels per tester - Any rate programming with ppm accuracy - Programmable voltage and timing levels - Sophisticated signal parameter (e.g. rise time, skew) measurement

| Serial & Parallel BERTs

	SV1C-14 Personalized SerDes Tester	SerDes tester for clock forwarded and embedded clock applications up to 14.1 Gbps
	SV1C-12 Personalized SerDes Tester	SerDes tester for clock forwarded and embedded clock applications up to 12.5 Gbps
	SV1C-8 Personalized SerDes Tester	SerDes tester for applications up to 8 Gbps
	SV1C-4 Personalized SerDes Tester	SerDes tester for applications up to 4 Gbps

| Probe Products

	RSH2 Remote Sampling Head	12 Active Probes Integrated Into a Clean, Shielded Form Factor
	RSH1 Remote Sampling Head	Clean Probing of Parallel Buses
	PV2 Universal Active Probe	Probing Solution with 8 GHz Bandwidth
	PV1 Universal Active Probe	Probing Solution with 5 GHz Bandwidth

| Video Demo

PV2 8 GHz Active Probe Introduction
