MIPI Control and Data

Rapidly evolving conduits for a broad range of imaging applications
| Probe Products | Digital IO Test Modules |

견적 요청 자료실

| 제품 설명

In support of its high-speed interface specifications, MIPI® Alliance has created a group of protocol layers for controlling and managing low-speed components. These protocol layer standards are grouped under the MIPI Control and Data family of specifications. Examples of components defined by these standards are the various sensors that exist on a smart phone and the various components related to audio processing. Defining standard protocols for controlling these components helps shorten time to market and enhances product robustness. The reason is that an entire ecosystem of IP providers, simulation vendors, and test and measurement manufacturers exists to support the development of these protocols.

Introspect Technology’s E Series modules and probes are ideal for the design and debug of control and data interfaces such as those defined by MIPI Alliance.

Industry Challenges	Introspect Capability
- Supporting complex control and data protocols in short time frames - Creating interoperability systems for validation and debug	- Complete exercising and protocol analysis of low-speed protocols - Low cost, high bandwidth, and multi-channel active probe solutions - PurVue Analyzer™: Brand new I3C protocol-triggered real-time oscilloscope compatible with the SV6E-X Mid-Frequency Digital Test Module, thus eliminating the need for external active probes or benchtop oscilloscopes

| Probe Products

	PV2 Universal Active Probe	Probing Solution with 8 GHz Bandwidth
	PV1 Universal Active Probe	Probing Solution with 5 GHz Bandwidth

| Digital IO Test Modules

	SV6E-X: SoundWire	Enabling high performance testing of SoundWire
	PurVue Analyzer™	Highly Commended Embedded Real-time Oscilloscope for SV6E-X

| 자료실

제 목	파일 다운로드
[동영상] SV5C-DPRXCPRX: High-Performance Combo MIPI D-PHY and C-PHY Analyzer	AVI
[동영상] SV5C-DPTXCPTX Combo MIPI D-PHY/C-PHY Generator	AVI
[Introspect] MIPI D-PHY/C-PHY 솔루션을 소개해 드립니다.	PDF
[제품 사양서] SV6E-X 제품 사양서	PDF
DDR5 DIMM 메모리의 기능테스트(Functional Test) 방법을 소개합니다.	PDF
DDR SPD Hub Device 검증방법 알아보기	PDF
[소개자료] High Speed Digital 솔루션의 강자 Introspect를 소개합니다.	PDF
