SV7C-eDP Embedded DisplayPort Generator

Ultra-Portable, High-Performance Generator for eDP up to v2.0 and DP up to 2.1 in HBR and UHBR

견적 요청 자료실

| Benefits

Supports Embedded DisplayPort (eDP) up to v2.0 and DisplayPort (DP) up to v2.1 in HBR and UHBR
Unique features for stressing a DisplayPort sink device, including per-lane voltage amplitude, common-mode voltage control, jitter injection, sinusoidal voltage noise injection, and per-wire timing skew.
An all‐in‐one system that enables the simplest bench environment for physical layer test to full protocol layer validation
Full video frame generation with 8 GBytes of total pattern memory
Leverages the full power of Python and award-winning Introspect ESP Software. Scripting capability is ideal for debug tasks and for full‐fledged production screening of devices and systems

| Features

The SV7C-eDP Embedded DisplayPort Generator is an ultra-portable, high-performance instrument capable of generating traffic for Embedded DisplayPort up to v2.0 and DisplayPort applications up to v2.1. The SV7C-eDP Generator provides analog parameter controls that enable DisplayPort receiver stress-testing and allow for deep insights into voltage and timing sensitivities of DisplayPort sink devices. The instrument operates with the award-winning Pinetree software environment which includes full pattern synthesis tools for generating test patterns and video frames for system-level test.
